Diamond 11.CS Centre Speaker

Sold Out $699.99

The Diamond 11.CS is a two-way centre-channel speaker — the larger centre for a Diamond 11 home cinema, voiced to match the floorstanding models. Twin 5" (130 mm) woven Kevlar® drivers flank a 1" (25 mm) textile-dome tweeter for clear, weighty dialogue even at higher levels.

Built on an 11 L cabinet crossing over at 2.6 kHz, the 11.CS covers a 65 Hz – 20 kHz response up to a 102 dB peak SPL. At 87 dB sensitivity and 8 Ω (4.2 Ω minimum), it handles amplifiers from 25 to 150 W with ease.

It is the larger centre of the Diamond 11 Series — the ideal match for the 11.2 standmounts or the 11.3, 11.4 and 11.5 floorstanders. See all our centre speakers.

Wharfedale Australia is the official, AVR-authorised distributor — every Diamond 11.CS is backed by genuine Australian warranty and local support.

Champagne Speakers on a Beer Budget.

The most loved Wharfedale loudspeaker is ready to make your ears drool all over again. Available in Black, White, Rosewood and Walnut, the new Diamond 11 series features slot-loaded bass ports, the latest generation Diamond drive units, kevlar woven cones and a sandwiched cabinet construction. The result, our best Diamond series to date and your most affordable high-end audio experience. And with a wide range of bookshelf, floorstanding and centre channel options, there’s the perfect Diamond 11 loudspeaker to suit your listening space.

High-end drivers. Low-end cost. It’s music to your ears

With massive ceramic magnets to extend the midrange response and provide absolute cone control, the listening experience is breathtaking. Vocals are wonderfully textured, instruments beautifully expressive. A newly evolved tweeter design delivers crisp, detailed high-frequencies while the slot-loaded bass port improves overall low-frequency performance. This makes each Diamond loudspeaker in the series a true all-rounder, perfectly compatible with every album in your collection, every new release, EP, and playlist on your provider. Let’s face it, you’re going to fall in love with music all over again.

Make Movie Night Every Night.

Diamond 11.CS is a 2-way centre channel loudspeaker featuring a 25mm textile dome tweeter and 2 x 100mm woven kevlar bass drivers. Combined with a smaller chassis (145mm x 420mm x 138mm), Diamond 11.CS is perfect for small to medium sized living rooms and home theatre spaces. And at only 5.8kg, you can enjoy all the dynamics, all the clarity, all the texture of high-fidelity audio from a smaller, more subtle centre channel speaker. You’ll never miss a single word of dialogue again. Experience home theatre like never before thanks to Diamond 11.CS

Technical Specifications

Description	2 Way Centre Speaker
Enclosure Type	Bass Reflex (down ported)
Bass Driver	2 x 130mm (5") Woven Kevlar cone
Tweeter	25mm (1") soft dome
Frequency Response (+/-3dB)	65Hz - 20kHz
Sensitivity (2.83V@1m)	90dB
Recommended Amplifier Power	25W-150W
Nominal Impedance	8 Ohms Compatible
Dimensions (H x W x D) in mm	170 x 480 x 200
Weight	6.1kg
Stocked Colours	Blackwood, Rosewood, Walnut, White Sandex
